eSIM silently (without user interaction) downloaded to the device and successfully activated

Hey, thanks for posting, great question!


I'm not sure I can do it full justice myself, but one of our community experts, Jason, has actually written up the AMAPI eSIM management flow in some detail, which might be worth a read as a starting point: Is it possible to manage eSIM? | Jason Bayton


Tagging ​@jasonbayton to see if he has any specific insight on the activation code requirement and whether there's a workaround available for your use case!

AMAPI's AddEsimParams.activationCode is mandatory by Google's design. I’m not sure I draw the same conclusion as you from the docs..

The activation code is the destination from which the profile is downloaded, it can either be a full profile or a partial profile, in the latter you don’t provide an activation code with a full eSIM configured, but rather point to an SM-DP+ server that has device identifiers mapped to an eSIM config on that end. If you want the admin not to type a code, the EMM has to fetch one via direct integration with the carrier. The EMM then calls AMAPI's AddEsim with the carrier-supplied code and the user sees nothing.

I’ve implemented this a couple of times to date, perhaps these references will help:

• netlify/functions/_lib/amapi-command.ts (ADD_ESIM validation) - ADD_ESIM throws AmapiCommandValidationError('ADD_ESIM requires params.activationCode') if the field is missing.
• src/components/device/CommandModal.tsx (Add eSIM form) - the UI marks activationCode as required: true with an LPA:1$smdp.example.com$... placeholder.

From a usage standpoint,

• The EMM user obtains an LPA activation code from the carrier / SM-DP+ provider independently - typically a string like LPA:1$smdp.example.com$MATCHING_ID.
• Submits it via the Add eSIM command. Flash sends addEsimParams.activationCode plus activationState (defaulting to ACTIVATION_STATE_UNSPECIFIED if you don't set it - see amapi-command.ts ADD_ESIM body construction).
• On a fully managed device running Android 15+, AMAPI downloads and activates the profile with no user interaction.

If you literally don't have an activation code, your real question is for the SM-DP+/carrier, not the EMM - ask them to issue an activation code (or per-device matching IDs) you can feed into addEsimParams. AMAPI has no EID-only download path today.

Thanks for the ping ​@Kirk :)

To be honest i would wonder if an activation code is NOT required.

I see my assumption agreed viewing this documentation: https://source.android.com/docs/core/connect/esim-overview#activation-code

A​lso as @Kirk points to ​@jasonbaytons documentation, there the activation code is not stated as optional which would fit my assumption as well.
